The diagram below illustrates the key components and their interactions within the sphinx-diagram-connect extension. This overview helps in understanding how the extension integrates with the Sphinx build process to resolve references in SVG diagrams.

@startuml title <SIZE:40>Sphinx-Diagram-Connect Component Diagram</SIZe> scale 0.44 skinparam backgroundColor transparent 'skinparam backgroundColor #b5b4a8ff skinparam defaultFontSize 30 skinparam defaultText { FontColor #000000 } skinparam component { BackgroundColor #ADD8E6 BorderColor #336699 FontColor #000000 } skinparam package { BackgroundColor #FFFFE0 BorderColor #CCAA66 FontColor #000000 } skinparam database { BackgroundColor #90EE90 BorderColor #006600 FontColor #000000 } skinparam folder { BackgroundColor #B0E0E6 BorderColor #4682B4 FontColor #000000 } skinparam file { BackgroundColor #F5F5F5 BorderColor #696969 FontColor #000000 } package "Sphinx Documentation Build" #FFFFE0 { [Sphinx Application] as SphinxApp #ADD8E6 [Sphinx Builder (HTML)] as SphinxBuilder #ADD8E6 [conf.py] as Config #F5F5F5 } package "Sphinx-Diagram-Connect Extension" #FFFFE0 { [DiagramConnect Class] as DCClass #ADD8E6 [resolve_references Method] as ResolveRefs #ADD8E6 [NeedsList Class (from sphinx-needs)] as NeedsList #ADD8E6 } database "Sphinx Output Directory" #90EE90 { folder "SVG Files" as SVGs #B0E0E6 file "needs.json" as NeedsJSON #F5F5F5 } SphinxApp -right-> Config : loads configuration Config --> DCClass : config values\n(`verbose`) SphinxApp -right-> DCClass : instantiates,\nregisters event SphinxBuilder .down.> SVGs : generates\nSVG content SphinxBuilder .right.> NeedsJSON : generates\nneeds.json\n(if needs enabled) SphinxApp .down.> ResolveRefs : `build-finished`\nevent trigger ResolveRefs --> SVGs : reads/writes SVG content ResolveRefs ..> NeedsJSON : reads needs.json\n(via `_init_needs`) DCClass ..> NeedsList : utilizes ResolveRefs --> SphinxBuilder : logs warnings/info @enduml
